SKU:
PR706013
Tiger Subsea Chain Block 3.2T, 3.0m
$6,187.00
Unit price
/
Unavailable
** Please note this item may have a longer delivery time. For urgent orders please enquire about excepted dispatch date prior to purchasing **
The Tiger Subsea range was designed for underwater use in the Oil & Gas industry however the same anti-corrosion design makes them ideal for use in harsh environments such as water treatment plants, chemical plants, shipping industry and general marine and coastal applications.
Fully corrosion protected body and components to ensure reliable long term use
Marine specific friction discs
Double cover protection for brake chamber
Guaranteed 2% light load protection
-40 C to +50 C operating temperature range
Tested and certified for fleeting, drifting and cross-hauling applications up to 45 from the vertical without deration
Fitted with load bearing swivel hooks to meet AS1418.2
Complies with BS EN 13157:2004+A1:2009, ANSI/ASME B30.21-2005, AS 1418.2:1997 and SANS 1636
DNV GL Verification tested according to NORSOK R-002
TECHNICAL SPECIFICATIONS
TERM
DESCRIPTION
Rated Capacity
3.2 tonne
Lifting Height
3m
No. of Load Chain Falls
1
Load Chain Diameter
10.0mm
Headroom
550mm
The Tiger Subsea range was designed for underwater use in the Oil & Gas industry however the same anti-corrosion design makes them ideal for use in harsh environments such as water treatment plants, chemical plants, shipping industry and general marine and coastal applications.
Fully corrosion protected body and components to ensure reliable long term use
Marine specific friction discs
Double cover protection for brake chamber
Guaranteed 2% light load protection
-40 C to +50 C operating temperature range
Tested and certified for fleeting, drifting and cross-hauling applications up to 45 from the vertical without deration
Fitted with load bearing swivel hooks to meet AS1418.2
Complies with BS EN 13157:2004+A1:2009, ANSI/ASME B30.21-2005, AS 1418.2:1997 and SANS 1636
DNV GL Verification tested according to NORSOK R-002
TECHNICAL SPECIFICATIONS
TERM
DESCRIPTION
Rated Capacity
3.2 tonne
Lifting Height
3m
No. of Load Chain Falls
1
Load Chain Diameter
10.0mm
Headroom
550mm
