Tiger Brake Hand Winch 1200kg

The Tiger Brake Winch is a high quality multi-purpose winch used for a wide variety of lifting and hoisting applications. The automatic brake ensures the load remains suspended when the crank is released and avoids unchecked descent of the load; there is no freewheeling making the hand winch extremely safe to operate. All the mechanical components are enclosed for protection against dust, dirt and rain contamination. The BHW is compact and lightweight yet rugged and durable.
Automatic load-actuated brake can hold the load in any position
Compact, light-weight and rugged construction
Gears and brakes fully covered to prevent dust, dirt and rain contamination
Heavy Duty heat treated gears
Very low operator effort required for easy operation
Universal mounting plate
Suitable for cable or strap
Finished in high quality powder coat paint offering excellent corrosion protection
Operating temperature of -20 C to +80 C

TECHNICAL SPECIFICATIONS
TERM
DESCRIPTION
Mfr No.
WHW-NW-1200-BHW2600CRTG
Lifting Capacity
590kg
Pulling Capacity
1200kg
Gear Ratio
10:1
Wire Storage Capacity
18m (8mm)
