Description
LOCTITE 609 is a green, high strength methacrylate ester acrylic retaining compound designed for the bonding of cylindrical fitting parts. The product cures in the absence of air between close fitting metal surfaces.
Typical applications include rotor to shafts in fractional and subfractional horsepower motors. Locks bushings and sleeves in housings on shafts
Prevents fretting corossion, offers excellent load transmissions and chemical resistance
Augments press fits
Dismantles with press
Evenly distributes loads and stresses
Low viscosity
Recommended Primer - LOCTITE 7649 (NZSB Code: 05133309) / LOCTITE 7471 (NZSB Code: 05202502) Refer to TDS
Recommend Cleaning/Surface Preparation - LOCTITE SF 7063 (Code: 427410)
TECHNICAL SPECIFICATIONS
Term / Description
Mfr No. 30015
Applcation Retaining - Securing Metal Cylindrical Assemblies
Strength Medium/High
Appearance Green Liquid
Cure Anaerobic
Temperature Range -55C to +150C
Fixture Time 10min
Shear Strength, Grit Blasted Steel 2300psi
Gap Fill 0.15mm
Viscosity Low
Typical applications include rotor to shafts in fractional and subfractional horsepower motors. Locks bushings and sleeves in housings on shafts
Prevents fretting corossion, offers excellent load transmissions and chemical resistance
Augments press fits
Dismantles with press
Evenly distributes loads and stresses
Low viscosity
Recommended Primer - LOCTITE 7649 (NZSB Code: 05133309) / LOCTITE 7471 (NZSB Code: 05202502) Refer to TDS
Recommend Cleaning/Surface Preparation - LOCTITE SF 7063 (Code: 427410)
TECHNICAL SPECIFICATIONS
Term / Description
Mfr No. 30015
Applcation Retaining - Securing Metal Cylindrical Assemblies
Strength Medium/High
Appearance Green Liquid
Cure Anaerobic
Temperature Range -55C to +150C
Fixture Time 10min
Shear Strength, Grit Blasted Steel 2300psi
Gap Fill 0.15mm
Viscosity Low
