Projecta - Digital Multimeter

A convenient and reliable entry level multimeter with simple rotary switch to quickly select the function and range to be measured.

FEATURES
LCD screen
Large and easy to read data screen

Program selector
Quick and easy program selection via turn dial

Transistor check
Convenient transistor test, displays hFE measurement


SPECIFICATIONS
POLARITY
Auto indication (-)

VOLTAGE
DCV: 200mV, 2000mV, 20V, 200V & 1000V
ACV: 200V & 750V (45–450Hz)

CURRENT
DCA: 200?A, 2000?A, 20mA, 2000mA & 10A

RESISTANCE
200 Ohm, 2000 Ohm, 20k Ohm, 200k Ohm & 2000k Ohm

DRY CELL BATTERY CHECK
1.5V (AAA, AA, C & D) & 9V

DIODE TEST
1mA current for forward Vdrop

TRANSISTOR TEST
hFE (0–1000) @ 3.2Vce

ACCURACY
< ± 1.0% full scale reading

BATTERY
9V dry cell

INTERNAL FUSE
M205 (F500mA)

LOW BATTERY WARNING
7.5V

SIZE
126mm x 69mm x 24mm

WEIGHT
115g

Brand - PROJECTA
A convenient and reliable entry level multimeter with simple rotary switch to quickly select the function and range to be measured. The device possesses a large LCD screen which makes it easy to read data. Quick and easy program selection via turn dial. Convenient transistor test, displays hFE measurement.
Simple rotary switch.
Polarity auto indication.
Range of AC/DC voltage check ranges.
Range of current and resistance check ranges.
LCD screen
Program selector
Transistor check
